• Advertise on RCU • Buy RCU Keywords • Audiocasts with Erick Royer • Product Buy Now Ads • RCU Free Speech Policy > e-Station BC6 Balancing Charger e-Station BC6 Balancing Li-po / A123 charger AC/DC power Product Type: Chargers Manufacturer: Bantam Product: e-Station BC6 Balancing Charger Battery: Li-Ion, Li-poly, Li-Fe, NiCD, NiM, Pb Power I/O: AC and DC / 1-6 lipo cells, 1-15 NiCD Charge / Discharge: 5A / 1A Street Price: $169.95 Website: Phone Orders: 773.203.8695 Specification Operating voltage DC 11~18 volts AC 100~240V, 50/60Hz Charge/discharge power max. 50/5 Watts NiCd/MH 1~15 cells LiIo/LiPo/LiFe 1~6 series Pb 2~20V Charge current 0.1 to 5.0A Discharg current 0.1 to 1.0A No. Of cycle 1 to 5 times Battery data memory up to 5 data Weight 1000g Dimension 160x120x40 mm. Optimized operating software When charging or discharging, BC6 has an 'AUTO' function that sets the feeding current or the cell count of Lithium battery automatically. Especially for Lithium batteries, it can prevent the over-charging can lead to an explosion by users fault. Every program in the unit is controlled with mutual links and communication for every possible error so it introduces a maximum safety. These can be set at users option.

- Dual input power BC6 employs the circuit that can be operated with the input power of AC(Alternating Current) or DC(Direct Current). For AC input, it contains a AC-DC switching power supplier which has 5A of power capacity and maximum output power of 50Watts for charging.

As a result it can charge up to 16 cells of NiCd/NiMH and 6 series of Lithium batteries with maximum current of 5.0A. - Individual voltage balancer for Lithium batteries inside BC6 has an individual-cell-voltage balancer inside. So it does not need any balancer separately when charging Lithium batteries (LiIo/LiPo/LiFe) for cell voltage balancing. - Balance individual cells on discharge BC6 also can monitor and balance individual cells of the Lithium battery pack during the discharge process.

If the voltage of any one cell varies abnormally, the process will be stopped with the error message. - Accept various types of Lithium battery BC6 can accept three types of Lithium batteries - LiIo, LiPo and LiFe. They have different characteristics by their chemistry. You can select any one of them that you are going to process before the job. - Lithium battery 'Fast' and 'Storage' mode You can charge Lithium battery for special purposes. 'Fast' charge reduces the charging time of Lithium battery and 'Storage mode controls the final voltage of the battery to be suit for long time storage.

- Data store/load For users convenience it can store maximum 5 data of different batteries. You can establish the data contains program setting of the battery to charge or discharge continually. These data can be called out at any time you need and the process can be executed without program setting. - Cyclic charging/discharging Perform 1 to 5 cycles of charge>discharge or discharge>charge continually for battery refreshing and balancing. - PC based analysis using USB communication For technical expert, BC6 offers PC based program can analysis the characteristic of the battery by USB port. It shows a graph of voltage, current, capacity and temperature curves. It also shows the individual voltage of each cell in the Lithium battery pack.

- Robust outer aluminum case High-quality aluminum case is durable and very efficient to cool out the internal heat. Accessories EAC110 Temperature sensor cable EAC117 4mm gold banana plug with silicon cable and alligator clips EAC120 8-pin cable for individual cell connector EAC200 Charge graph program kit (CD USB cable) Remember to mention that you saw it on RCUniverse.com!
